2G 3G 4G 5G 1710-2700MHz Outdoor Patch Panel Antenna 17dbi High gain Dual Band Mimo Antenna Base Station Antenna

Brand Name : OEM

Model Number : BIO-G601

Certification : CE IOS ROHS SGS

Place of Origin : Guangdong, China

MOQ : 100 Pieces

Price : $80/Pieces 100-999 Pieces

Payment Terms : L/C, T/T, D/P

Supply Ability : 1000000 Piece/Pieces per Month

Packaging Details : PE bage

Delivery Time : 15

Product name : 4G 5G base station antenna

Frequency Range : 1710-2700MHz

Polarization : Linear

VSWR : ≤1.5

Connector : N-K

Size : 1200*160*70mm

Contact Now

2G 3G 4G 5G 1710-2700MHz Outdoor Patch Panel Antenna 17dbi High gain Dual Band Mimo Antenna Base Station Antenna

Specifications
Product Name	4G 5G Base Station Antenna
Brand	Baiao / OEM
Model Number	BIO-G601
Frequency Range	1710-2700MHz
Gain	17±0.5dBi
Horizontal Beamwidth	65±5 o
Vertical Beamwidth	8±3o
F/B Ratio	≥25dB
VSWR	≤1.5
Isolation	≥28dB
Impedance	50 Ω
Polarization	Vertical polarization
Max. Power	100W
Connector	N-K
Lightning Protection	Dc ground
Prodcut Specifications
Product size	1200x160x70mm
Weight	5.2kg
Rated Wind Velocity	36.9 m/s
Reflector material	Aluminium/Copper
Operational Humidity	< 95
Radome Color	off-white
Radome material	PVC
Operating temperaturec	40～55o
Suitable pole diameter	￠40～￠80
Packing	PE bag / Color box / Customization
Certificate	CE / FCC / RoHs / REACH
Do you want to know more types of products? Please click here

Advantages &special

•Direct factory have better control in the quality and lead time of Antenna Shipment
•All production operations comply with ISO 9001:2015 international quality standards.

We also have RoHS, CE, and REACH certifications available for All the Antennas.
•8 R&D engineers with more than 15 years of Antenna industry experience
•OEM/ODM high-end customized service to meet the requirements of different customers.
•24H /7D after sales services

FAQ

Q : Do you offer samples?
A : Yes, we offer samples for testing.

Q : What's your MOQ?
A : Our MOQ is 500pcs, the first order is negotiable.

Q : How do you test your prouducts?
A : We use network analyzer (Agilent 8714ET/HP-8714ET) to test the antennas’
VSWR,lmpedance,Smith Chart and Frequency in the simulation environment.

And conducting instrument to test the cable.

Q : How far your company from Shenzhen?
A : It only takes 30 minutes from Luohu railway station to Changping railway station by

CRH China Railway High-speed.

Q : Do you make OEM products?
A : Yes,we can do.

Q : Do you have RoHS certification?
A : We can do RoHS certifiction according to customers’ requirements.
The customers need to charge the handing fee.Or we can provide customers the SGS report of the

material for free.
